This type of isolator is also named as the polarized optical-isolator in a new face. This is an independent polarized type optical-isolator, which can be used in EDFA optical amplifier which includes different components like wavelength-division multiplexer (WDM), erbium-doped fiber, pumping diode laser, etc. The latter is more complicated and often used in EDFA optical amplifier. Also, there are dependent and independent polarized optical-isolators. It allows light to transmit in forwarding direction, however, prohibits every light beam to transmit back. This detector is surrounded by an optically transparent high voltage insulation material. 1 shows that the LED’s optical flux is also received by a PIN photodiode located on the output side (pins 5, 6) of the coupler package. This isolator uses the polarization axis to keep light transmit in one direction. current needed to servo the input stage of the isolation amplifier. Optoisolators are classified into three types which include Polarized, Composite, and Magnetic optical-isolator Polarized Type Optical-Isolator Thus, the light beam will be either absorbed or reflected. After that, the 90° polarization light turns into vertical toward the i/p polarizer & cannot depart the isolator.
When it transmits throughout the Faraday rotator, rotates continuously for another 45° in a similar path. Similarly in backward mode, initially the light enters into the o/p polarizer with a 45°. Therefore, finally, the light leaves from the o/p polarizer at 45°. Once the light beam arrives at the Faraday rotator, then the rod of the Faraday rotator will turn with 45°. In forward mode, the light enters into the input polarizer then becomes linearly polarized. The operation modes of this isolator are classified into two types based on the different directions of light such as forward mode & backward mode. The working of this is like when light passes through the i/p polarizer in the forward direction & turn into polarized within the vertical plane. The block diagram representation is shown below. An optical isolator includes three main components namely a Faraday rotator, i/p polarizer, & an o/p polarizer.
